PDF417

Description of PDF417

ActiveBarcode: PDF417PDF417 is a two-dimensional (2D) code based on stacked barcodes (stack code). The characters used are encoded in codewords. Each codeword consists of 17 modules, each of which consists of four bars and four spaces.

PDF417 is a highly compact and flexible code with variable length. Up to 1,108 bytes can be encoded.



Error Correction Level:
PDF417 uses a different error correction level (ECL) depending on the code length. If fewer than 41 codewords are used, ECL2 is employed. For 41-160 codewords, ECL3 is used. For 161-320 codewords, ECL4 is used. For 321 or more codewords, ECL5 is used.

PDF417 Barcode
Example of a PDF417 with ECL2

PDF417 Barcode
Example of a PDF417 with ECL3

PDF417 Barcode
Example of a PDF417 with ECL4

PDF417 Barcode
Example of a PDF417 with ECL5



Another example of a PDF417:PDF417 Barcode
In this PDF417, the German umlauts, among others, are encoded for demo purposes.



More information about this can be found at https://en.wikipedia.org/wiki/PDF417.

Technical data

Valid characters:
Length: Variable with no fixed length.
Check digit: none
Type#: PDF417 - #36 - CODEPDF417
Info: This barcode types has no human readable text based on the specification. The ShowText property has no effect, when using one of this codes.
